Rigol DG5251 1 Channel Function/Arbitrary Waveform Generator 250MHz 1GSa/s 14 bits 128Mpts

• The listing picture is DG5352 model, but please note what you are buying is DG5251 model.
• •250 MHz bandwidth
• •1 GSa/Sec waveform output
• •14 bit vertical resolution
• •128 Million Points of Arbitrary Waveform Memory

Introduction:

DG5251 is a multipurpose generator combining different capabilities including Function Generation, Arbitrary Waveform Generation, IQ Baseband Source/IQ IF Source, Frequency Hopping Source (optional) and Pattern Generation (optional). With single and true, independent, dual-channel models that provide adjustable phases between the two channels. The DG5251 adopts Direct Digital Synthesizer (DDS) technology, which providing stable, precise, low distortion signals. The user-friendly interface design and panel layout improves efficiency or utilize an interface for complete programmability.

Features:

•250 MHz bandwidth
•1 GSa/Sec waveform output
•14 bit vertical resolution
•128 Million Points of Arbitrary Waveform Memory
•Built in standard modulations including IQ modulation for digital baseband generation including QPSK and QAM formats
•Standard Interfaces including LXI-C (Ethernet), USB device and host, and GPIB
•Options including output amplifier (PA-1011), digital generator (DG-POD-A), and frequency hopping capability

Specifications:

Channels:1
Frequency:250 MHz
Sample Rate:1 GSa/s
Waveform Length:Up to 128 Million points
Resolution:1 µHz
Amplitude range:5 mVpp - 10 Vpp(50 O),10 mV - 20 Vpp(into open circuit)
Vertical Resolution:14 bits
Standard Interface:USB Host(2),USB Device, GPIB, LXI-C (Ethernet)
Options:Hop Frequency Module, Logic Signal Output Module, Power Amplifier

Product Weight: 0.65 LB
