Rigol DS2072A-S 70 MHz Digital Oscilloscope with 2 channels + 2-channel Signal Source

• 70 MHz, 2 Channel Oscilloscope with 2 GSa/sec and 14 Mpts memory standard as well as low noise front end. 50 Ohm input and 2 ch source embedded
• 70MHz Bandwidth
• Dual impedance inputs (50Ohm/1MOhm)
• 14 million memory points standard
• 65,000 frames of waveform recording

70MHz,2-channel + 2-channel Signal Source.14 million memory points standardWider vertical range(500uV/div ~ 10V/div), lower noise floor, better for small signal capturingFull bandwidth, lower overshoot(Up to 256 Levels intensity grading waveform displayA variety of trigger and optional RS232,I2C,SPI serial bus decording functions (opt SD-DS2)Complete connectivities :USB Host,USB Device,LAN(LXI),AUXDS2000ASeries Digital OscilloscopesDS2000A Series is the new mainstream digital scope to meet the customer's applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities.Innovative UltraVision technology Deeper Memory Depth (Std.14Mpts,Opt.56Mpts) Higher Waveform Capture Rate (Up to 50,000 wfms/s) Realtime Waveform Record,Replay & Analysis (Up to 65,000 frames) Multi-level Intensity Grading Display (Up to 256 Levels..Models and Key Specification Model Number DS2072A DS2072A-S DS2102A DS2102A-S DS2202A DS2202A-S DS2302A DS2302A-S Analog BW 70 MHz 100MHz 200 MHz 300 MHz Channels 2 Max. Sample rate 2GSa/s (Single-channel)? 1GSa/s(Dual-channel) Max. Memory Depth 14Mpts(std.)?56Mpts(option) Max. Waveform Capture rate 50,000 wfms/s Real Time waveform Record, Replay and Analysis function Up to 65,000 Frames Std. Probes RP3300A 350MHz BW Passive Probe:2 sets Built-in 2Ch 25MHz Source No Yes No Yes No Yes No YesFeatures and Benefits Wider Vertical range(500uV/div~10V/div), Lower noisefloor, Better for small signal capturing

Product Dimensions (L x W x H): 427 x 290 x 284 MM

Product Weight: 1.4 LB
