3.2 GHz Spectrum Analyzer | As of 4/1/2017 - Includes Preamplifier Option PA-DSA832Standard(Previously a $599 add on) | 9 kHz to 3.2 GHz Frequency Range | Displayed Average Noise Level (DANL) normalized to 1 Hz ranging from -135 dBm to -161 dBm typical | -80 to -98 dBc/Hz at10 kHz offset Phase Noise

Rigol DSA832 - Bandwidth Range Max: 1.5 Ghz, Bandwith Range Min: 9 kHz

01DSA832
Regular price
$6,499.61
Sale price
$6,499.61
Regular price
Sold out
Unit price
per
Shipping calculated at checkout.

  • 3.2 GHz Spectrum Analyzer
  • As of 4/1/2017 - Includes Preamplifier Option PA-DSA832Standard(Previously a $599 add on)
  • 9 kHz to 3.2 GHz Frequency Range
  • Displayed Average Noise Level (DANL) normalized to 1 Hz ranging from -135 dBm to -161 dBm typical
  • -80 to -98 dBc/Hz at10 kHz offset Phase Noise
3.2GHz Spectrum AnalyzerRigol DSA832 9 kHz to 3.2 GHz, Spectrum AnalyzerxIF Design Benefits The ability to measure smaller signals: on the basis of this technology, the IF filter enables smaller bandwidth settings, which greatly reduce the displayed average noise level. The ability to distinguish between small signals by frequency: using the IF filter with the smallest bandwidth setting, it is possible to make out signals with a frequency difference of only 10 Hz. High precision amplitude readings: this technology almost eliminates the errors generated by filter switching, reference level uncertainty, scale distortion, as well as errors produced in the process of switching between logarithmic and linear display of amplitude when using a traditional analog IF design. Higher reliability: compared with traditional analog designs, the digital IF greatly reduces the complexity of the hardware, the system instability caused by channel aging, and the temperature sensitivity that can contribute to parts failure. High measurement speed: the use of digital IF technology improves the bandwidth precision and selectivity of the filter, minimizing the scanning time and improving the speed of the measurement.DSA800 Series Spectrum AnalyzerRigol's DSA800 Series spectrum analyzers redefine the product category by setting new standards for performance and price. The DSA800 family features a widescreen display, compact design, and easy-to-use interface making it ideal for benchtop or field apps in RF and wireless testing and production. The spectrum analyzer offers the ability to measure smaller signals using our digital IF filter, which allows for smaller bandwidth settings and reduces displayed noise levels.The DSA815 distinguishes between signals with a frequency difference as little as 100 Hz. The DSA832 and DSA875 have RBW settable down to 10 Hz and a DANL (displayed average noise level

Product Dimensions (L x W x H): 457 x 305 x 279 MM

Product Weight: 0.15 LB
