GW Instek GDS-2062 LCD Color Display Oscilloscope with 2 Input Channels, 60MHz Bandwidth, 5.8ns Rise Time

• 60 MHz Bandwidth
• 2 Input channels
• 1GSa/s Real-time and 25GSa/s equivalent-time sampling
• Maximum 25k points record length
• Limited lifetime warranty

The combination of 1GSa/s real-time sampling rate (25GSa/s for ET sampling) and 25k point’s record length of the GDS-2000 series provides the highest value platform among all equivalent products available in today's market. The 27 auto measurement functions, FFT measurement, advanced triggering, 12 division horizontal display, time clock, frequency counter, Go/NoGO, multi-language screen menu, on-line help, Setup sequence and a lifetime warranty are all standard features of the GDS-2000 series. 2 input channels. USB host/device: USB printer and USB flash drive supported. Battery operation (optional). Color printout. Rise time: 5.8ns approximate. Sensitivity: 2mV/div to 5V/div (1-2-5 increments). Accuracy: +/-(3 percent x |Readout|+0.05 div x volts/div+0.8mV). Input coupling: AC, DC and Ground. Input impedance: 1M ohm+/-2 percent, 16pF. Polarity: normal and invert. Maximum input: 300V (DC+AC peak), CATII. Bandwidth limit: 20 MHz (-3dB). TFT LCD type: 5.6". Resolution: 234 (vertically) x 320 (horizontally) dots. Graticule: 8 x 10 divisions; 8 x 12 divisions (menu off). Brightness: adjustable. Go/NoGo output: 5V maximum/10mA TTL open collector output. RS-232 interface: DB 9-pin male DTE RS-232 interface. GPIB interface (option): fully programmable with IEEE 488.2 compliance. USB: USB host/device 2.0 full speed supported. Line voltage range: AC 100V to 240V, 48Hz to 63Hz, Auto selection. Measures 310mm width by 142mm height by 254mm depth. 4.3kg weight.

Product Dimensions (L x W x H): x 58 x MM

Product Weight: 2.5 LB
