1GS/s Real-Time and 25GS/s equivalent-Time Sampling | 25K Points Record Length Maximum | Large 5.6-in Ultra-bright TFT Color | Up to 27 Automatic Measurements | Three USB ports and one RS232 (standard)

Digital Osilloscope - 200mhz, 1gs/s, 2 Ch. With Rs-232, USB

01GDS2202
$2,554.25
$2,554.25
Sold out
Shipping calculated at checkout.
  • 1GS/s Real-Time and 25GS/s equivalent-Time Sampling
  • 25K Points Record Length Maximum
  • Large 5.6-in Ultra-bright TFT Color
  • Up to 27 Automatic Measurements
  • Three USB ports and one RS232 (standard)
200MHz bandwidth 2 channels, 1GS/s Real-Time and 25GS/s equivalent-Time Sampling, 25K point record length for analyzing complex signals, Large 5.6-in Ultra-bright TFT Color Wide-angle viewable area, 8 X 12 Division display, Three USB ports and one RS232 (standard). Free software (interface/storage) USB host supports flash drive storage and color printout, DC Battery Power Operation (optional) Up to 27 Automatic Measurements Video/Pulse Width/Event-Delay/Time-Delay Trigger. FFT Analysis (Selectable Filters) Up to 8ns Peak Detection, 'Program Mode' and 'Go-No Go' Function RS-232 and GPIB Interface, Multi-Language and Built-in On-Line Help ,Store waveform raw data (CSV files) Capture screen image as BMP files Print waveform via USB printer Record feature (saves video file). Trigger Modes: Auto-Level, AUTO, NORMAL, SINGLE, TV, Edge, Pulse Width Time-delay ,event-delay.

Product Dimensions (L x W x H): x 330 x MM

Product Weight: 2.5 LB
