This is a pack of 1000 10M ohm (10,000,000 Ω) carbon film resistors rated at 1/2 W (0.5 W) with ±5% tolerance and a 250 V maximum working voltage. Carbon film resistors use a thin carbon layer as the resistive element and are a common general-purpose choice for prototyping, repairs and teaching.
Key Features
- Resistance: 10M Ω (10,000,000 ohms)
- Power rating: 1/2 W (0.5 W)
- Tolerance: ±5%
- Maximum working voltage: 250 V
- Carbon film resistive element
- Pack of 1000
Specifications
| Resistance | 10M Ω (10,000,000 ohms) |
|---|---|
| Type | Carbon film |
| Power | 1/2 W (0.5 W) |
| Tolerance | ±5% |
| Max working voltage | 250 V |
| Quantity | 1000 resistors |
| SKU | 13.5510MPK1000 |
What's Included
- 1000 × 10M ohm carbon film resistors
Ideal For
Stocking a workbench, classroom or production line with 10M ohm, 1/2 W resistors.
Frequently Asked Questions
What is the color code for 10M ohms?
On the standard 4-band code, 10,000,000 Ω at ±5% reads brown, black, blue, gold.
What does ±5% tolerance mean?
The actual resistance can be up to 5% above or below the marked 10M Ω value.
Can I use a 1/2 W resistor in place of a 1/4 W one?
Generally yes, if it fits: a higher power rating only adds headroom. The 1/2 W body is physically larger, though.
