Rigol DG822 Function/Arbitrary Waveform Generator 25MHz, 2 Channels, 16 bit Vertical Resolution, 2Mpts Arbitrary Wave Length

01DG822
Regular price
$389.00
Sale price
$389.00
Regular price
Sold out
Unit price
per
Shipping calculated at checkout.

  • 25MHz Function Generator, 2 Channel, 125MSa/sec, 16Bit Resolution, 2M Memory
    25 MHz, two channel function generator
  • 2 Mpts memory depth (upgradeable to 8 Mpts)
  • High frequency stability: +-1 ppm; low phase noise: -105 dBc/Hz
  • Built-in high-order harmonic generator (at most 8-order harmonics)

RIGOL Function/Arbitrary Waveform Generator DG800 Series
The DG800 redefines the entry level waveform generator by bringing advanced capabilities like 16 bit high resolution, intuitive touch screen control, and a quiet fanless design to our most affordable line of generators.

Main Features

  • Unique SiFi II (Signal Fidelity II) technology: generate the arbitrary waveforms point by point; recover the signal without distortion; sample rate accurate and adjustable; jitter of all the output waveforms (including Sine, Pulse, etc.) as low as 200 ps
  • 2 Mpts memory depth (standard); 8Mpts memory depth (optional) per channel for arbitrary waveforms
  • Optional dual-channel with the same performance, equivalent to two independent signal sources
  • Sample rate up to 125MSa/s,vertical resolution 16bits
  • High frequency stability: ±1 ppm; low phase noise: -105 dBc/Hz
  • Built-in high-order harmonic generator (at most 8-order harmonics)
  • Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
  • Up to 160 built-in arbitrary waveforms, covering the common signals in engineering application, medical electronics, auto electronics, math processing, and other various fields
  • Arbitrary waveform sequence editing function available; arbitrary waveforms also can be generated through the PC software
  • Various analog and digital modulation functions: AM, FM, PM, ASK, FSK, PSK, and PWM.
