- Model: LM2596S DC-DC voltage reduction module
- Input Voltage: 3.2V ~ 40V
- Output Voltage: 1.25V ~ 35V
- Output Current: 3A ( maximum )
- Conversion Efficiency: 92% ( highest )
- Output ripple: <30mV
- Switching Frequency: 65KHz
- Size: about 43mm * 21mm * 14mm / 1.69 * 0.83 * 0.55 inches
- Working Temperature: -45 F ~ +85 F
- Connection port: IN + input positive IN - input negative OUT + output positive OUT - output negative
- Input Voltage Range: DC 3.2V to 46V ( the input voltage must be higher than the output voltage of 1.5V or more, and it can not be raised )
- Output Voltage Range: DC 1.25V to 35V voltage is continuously adjustable, and high efficiency ( maximum 92% ) maximum output current is 3A.
Note: This is a step-down module, so the input voltage must be higher than the output voltage
